Voltages / Frequencies
Standard Voltages are 380v-420 50Hz and 440-480 60Hz
Insulation
The insulation system's components are chosen to provide adequate defense against air humidity, chemically hostile gasses, and vapors.
According to IEC60085, all materials used to insulate the winding and winding ends fall under one of the insulating classes F or H:
-Copper wires insulated with enamel and having a temperature index of 200°C (Class F);
-Class F insulating sheet on polyester basis;
-Impregnation using polyester resin-modified fenolic resins (Class F);
IEC60085 specifies the minimum temperature for insulating materials.
Temperature Rise
The temperature rise of standard single-speed continuous (S1) motors is within the Class B limit. Temperature increases for pole-changing and higher power motors often fall inside the Class F limit.
TECHNICAL DATA
|
Type No. IE1 |
Rated output |
Rated Current |
Rated speed (r/min) |
Rated Current |
Rated speed (r/min) |
EFF % |
Power Factor cosφ |
Rated Torque N.m |
Locked Torque |
Locked Current |
Max Torque |
Noise level Lw dB(A) |
Weight (kg) |
|||||
|
KW |
HP |
IFL 380V A |
IFL 400V A |
IFL 420V A |
IFL 440V A |
IFL 460V A |
IFL 480V A |
Rated Torque TST/TFL |
Rated Torque IST/IFL |
Rated Torque TM/TFL |
||||||||
|
380 - 420V/50Hz |
440 - 480V/60Hz |
|||||||||||||||||
|
Synchronous speed 1500r/min |
||||||||||||||||||
|
IE1-80M1-4 |
0.55 |
0.75 |
1.57 |
1.49 |
1.42 |
1390 |
1.36 |
1.30 |
1.24 |
1665 |
71.0 |
0.75 |
3.8 |
2.4 |
5.2 |
2.3 |
58 |
15 |
|
IE1-80M2-4 |
0.75 |
1.00 |
2.05 |
1.95 |
1.85 |
1390 |
1.77 |
1.69 |
1.62 |
1665 |
73.0 |
0.76 |
5.2 |
2.3 |
6.0 |
2.3 |
58 |
16 |
|
IE1-90S-4 |
1.1 |
1.5 |
2.85 |
2.71 |
2.58 |
1400 |
2.46 |
2.35 |
2.26 |
1680 |
76.2 |
0.77 |
7.6 |
2.3 |
6.0 |
2.3 |
61 |
20 |
|
IE1-90L-4 |
1.5 |
2.0 |
3.68 |
3.50 |
3.33 |
1400 |
3.18 |
3.04 |
2.91 |
1680 |
78.5 |
0.79 |
10.3 |
2.3 |
6.0 |
2.3 |
61 |
23 |
|
IE1-100L1-4 |
2.2 |
3.0 |
5.09 |
4.84 |
4.61 |
1420 |
4.40 |
4.20 |
4.03 |
1700 |
81.0 |
0.81 |
14.9 |
2.3 |
7.0 |
2.3 |
64 |
31 |
|
IE1-100L2-4 |
3 |
4.0 |
6.73 |
6.39 |
6.09 |
1420 |
5.81 |
5.56 |
5.33 |
1700 |
82.6 |
0.82 |
20.3 |
2.3 |
7.0 |
2.3 |
64 |
35 |
|
IE1-112M-4 |
4 |
5.5 |
8.80 |
8.36 |
7.96 |
1440 |
7.60 |
7.27 |
6.97 |
1725 |
84.2 |
0.82 |
26.5 |
2.3 |
7.0 |
2.3 |
65 |
41 |
|
IE1-132S-4 |
5.5 |
7.5 |
11.7 |
11.1 |
10.6 |
1440 |
10.1 |
9.67 |
9.26 |
1725 |
85.7 |
0.83 |
36.5 |
2.3 |
7.0 |
2.3 |
71 |
60 |
|
IE1-132M-4 |
7.5 |
10.0 |
15.6 |
14.8 |
14.1 |
1440 |
13.5 |
12.9 |
12.4 |
1725 |
87.0 |
0.84 |
49.7 |
2.3 |
7.0 |
2.3 |
71 |
74 |
|
IE1-160M-4 |
11 |
15 |
22.5 |
21.4 |
20.4 |
1460 |
19.4 |
18.6 |
17.8 |
1750 |
88.4 |
0.84 |
72.0 |
2.2 |
7.0 |
2.3 |
75 |
108 |
|
IE1-160L-4 |
15 |
20 |
30.0 |
28.5 |
27.1 |
1460 |
25.9 |
24.8 |
23.8 |
1750 |
89.4 |
0.85 |
98.1 |
2.2 |
7.5 |
2.3 |
75 |
128 |
|
IE1-180M-4 |
18.5 |
25 |
36.3 |
34.5 |
32.8 |
1465 |
31.4 |
30.0 |
28.7 |
1755 |
90.5 |
0.86 |
120.2 |
2.2 |
7.5 |
2.3 |
76 |
158 |
|
IE1-180L-4 |
22 |
30 |
42.9 |
40.8 |
38.8 |
1465 |
37.1 |
35.4 |
34.0 |
1755 |
91.0 |
0.86 |
142.9 |
2.2 |
7.5 |
2.3 |
76 |
172 |
|
IE1-200L-4 |
30 |
40 |
58.0 |
55.1 |
52.5 |
1470 |
50.1 |
47.9 |
45.9 |
1760 |
92.0 |
0.86 |
194.9 |
2.2 |
7.2 |
2.3 |
79 |
241 |
|
IE1-225S-4 |
37 |
50 |
70.2 |
66.7 |
63.5 |
1475 |
60.6 |
58.0 |
55.6 |
1770 |
92.5 |
0.87 |
239.6 |
2.2 |
7.2 |
2.3 |
81 |
180 |
|
IE1-225M-4 |
45 |
60 |
85.0 |
80.8 |
76.9 |
1475 |
73.4 |
70.2 |
67.3 |
1770 |
92.8 |
0.87 |
291.4 |
2.2 |
7.2 |
2.3 |
81 |
305 |
|
IE1-250M-4 |
55 |
75 |
103.3 |
98.1 |
93.5 |
1475 |
89.2 |
85.3 |
81.8 |
1770 |
93.0 |
0.87 |
354.9 |
2.2 |
7.2 |
2.3 |
83 |
375 |
CONVERTER FED APPLICATION
IE1 three phase motors are appropriate for applications requiring variable or constant speed, such as pumps, fans, compressors, textile machines, and mechanical machines. An externally driven fan is used when the motor is running at a speed less than 50% of its rated speed while carrying a steady load.
