Keep your aquarium, fountain, or small garden pond clean with this QY submersible pump. Designed for quiet, energy-efficient operation, it ensures smooth water circulation and aeration. The adjustable flow rate allows customization for different water features, and its compact size makes it easy to hide in tight spaces. Safe for fish and plants, this pump is a must-have for hobbyists.
Pump
Max.immersion depth:5m
Max.liquid temperature: +40℃
Fluid temperature up to: +35℃
Pump Body: Cast Iron
Impeller: Cast Iron
Double sealing structure
Motor
Copper winding
Three Phase(380V/50Hz)/Continuous Work
Motor Housing: Cast iron
Shaft: Stainless steel welded shaft /45# steel be electroplated
Insulation class: B or F
Protection class: IPx8
Adopts oil-filled type structure
Anti burst Structure
PRODUCT PARAMETERS
|
Model |
Power |
MAX. Head |
MAX. Flow |
Outlet |
Frequency |
|
QY15-26-2.2 |
2.2kW |
26m |
15m3/h |
50mm |
50Hz/60Hz |
|
QY25-17-2.2 |
2.2kW |
17m |
25m3/h |
63mm |
50Hz/60Hz |
|
QY40-12-2.2 |
2.2kW |
12m |
40m3/h |
80mm |
50Hz/60Hz |
|
QY65-7-2.2 |
2.2kW |
7m |
65m3/h |
100mm |
50Hz/60Hz |
|
QY100-4.5-2.2 |
2.2kW |
4.5m |
100m3/h |
150mm |
50Hz/60Hz |
|
QY15-36-3 |
3kW |
36m |
15m3/h |
50mm |
50Hz/60Hz |
|
QY25-26-3 |
3kW |
26m |
25m3/h |
63mm |
50Hz/60Hz |
|
QY40-16-3 |
3kW |
16m |
40m3/h |
80mm |
50Hz/60Hz |
|
QY65-10-3 |
3kW |
10m |
65m3/h |
100mm |
50Hz/60Hz |
This QY submersible pump combines sophisticated energy-saving technology to produce robust water circulation while keeping low energy consumption, assuring crystal-clear pool water and decreasing operational costs.
